Specifications | Source Range | Measurement | |||
---|---|---|---|---|---|
Range | Accurace | Resolution | |||
1:0~1A/10A | 350~830nm | 0.3nm | 1.0nm | ||
d | 1:0~1A/10A | 380~780nm | 0.3nm | 1.0nm | |
lv | 1:0~1A/10A | 10~10000mcd | 5% | 0.1mcd | |
le | 1:0~1A/10A | 0.05~100mW/sr | 5% | 0.1W/sr | |
Cx, Cy | 1:0~1A/10A | 0~0.7 | 0.002 | 0.001 | |
Hw | 1:0~1A/10A | 1~1050 | 0.3nm | 1.0nm | |
v | 1:0~1A/10A | 0.01~100lm | 5% | 0.001lm | |
e | 1:0~1A/10A | 50W~10W | 5% | 1w | |
Applications | CCT[Tc], CRI[Ra], Optical Efficacy[K] | ||||
Spectrum ranage | UV, UV~Visible, Visible~IR, IR, UV~IR[Selectable] |
||||
Optical Power | 0.1mcd~100cd[Selectable] | ||||
Rank | Max.256Bin | ||||
Interface | Paralle[]/RS-232[]/GPIB[Optional] | ||||
Data Format | Excel[*, CSV]/TEXT/IMAGE[BMP] | ||||
POWER | 100~230 VAC, 50/60 Hz | ||||
Operating Temperature/Humidity | 5~40/Less than 95% realtive, non-condensing | ||||
Dimension | 160mm[W] x 260mm[D] x 130mm[H] |
