ELECTROMETER	C-V Analyzer
(1) Dark Current Measurement resolution : 100aA (2) CurrentMeasurementRange: 1fA ~ 20mA (3) <20uV burden voltage on lowest current range. (4) Input Bias Current :<3fA (5) Input Bias Current Noise: < 0.75fA p-p noise (6) 200T ohm input impedance (7) Voltage Measurement Range : 10uV ~ 200V (8) Voltage Source Range : 5mV ~ 1000V	(1) Measurement Capacitance:10fF ~2nF (20nF Expandable) (2) Measurement Sensitivity: 0.1fF (3) FrequencyRange: 100Khz, 1Mhz (Quasistatic Expandable) (4) CurrentMeasurementRange: 1fA ~ 20mA (5) Bias Waveform: DC, Stair, Dual Stair, Pulse (6) VoltageSourceRange : -200.0V ~ +200.0V in 5mV step (7) C-V, C-t measurement function
SAMPLE HOLDER	Industrial Personal Computer for Control
(1) TO-46 type available (2) Temperature controlled (3) Dark state provided	(1) Pentium-4 3.2GHz processor (2) Memory : 1G RAM (3) HDD : 200Gbyte (4) VGA : Integrated VGA (5) 17 inch TFT LCD monitor
HEATER CONTROLLER
- Temperature range : Ambient ~ 85℃ - Temperature resolution of ±0.1℃ - Control stability of up to ±0.1℃ - Pulse-width modulation of output : Selectable modulation frequency of 675 Hz or 2700 Hz Controls up to 680 W - Versatile alarm system: output 5 VDC at 25 mA Alarm cancel is selectable via computer - software communication or remote contacts Second sensor also configurable as a heat-sink over-temperature shut-down - Non-volatile memory retention of parameters
Dimension : 1,522mm[W] x 700mm[D] x 994mm[H]
