| ELECTROMETER | Heater controller |
| (1) Dark Current Measurement resolution : 100aA (2) CurrentSourceRange: 1pA ~ 100mA (3) Current Source Accuracy : ±(1.0% + 10fA) (4) CurrentMeasurementRange : 1pA ~ 20mA (5) Current Measurement Accuracy : ±(1.0% + 7fA) (6) VoltageSourceRange : 200mV ~ 200V (7) Voltage Source Accuracy : ±(0.02% + 600uV) (8) Voltage Measurement Accuracy: ±(0.012% + 350Uv) (9) ResistanceMeasurementRange : 2 Ω~20T Ω (10) Pass/fail limit test as fast as 500us per point |
(1) Temperature range : RT ~ 85℃) (2) Temperature resolution of ± 0.1℃ (3) Control stability of up to ± 0.2℃ |
| SAMPLE HOLDER | Industrial Personal Computer for Control |
| (1) On-demand Manufacture by Sample Type (2)Barrel for dark state(Dark room) with adapter (3) Temperature controlled by TEC: Water-cooling |
(1) Pentium-4 3.2 GHz processor (2) Memory : 1GB RAM (3) HDD : 200G (4) 17 inch TFT LCD monitor |
| Dimension : 420mm[W] x 424mm[H] | |
|---|---|
